Mass-use chlorine dioxide generator that continuously generates up to 12,000 g / h

* “Two-component method” using 24% sodium chlorite and 30-38% hydrochloric acid
* Many valuations of the amount generated, suitable for various applications
* Can be used by generating chlorine dioxide by various internal / external controls
* Calibration kit (option) enables confirmation and calibration of drug injection amount during operation.

model	ClO2 Amount generated (maximum) (g/h)	ClO2 Water concentration (mg/L)	Maximum chemical consumption		Reference amount of treated water (m3/h) *	size (mm)	mass (kg)	power consumption (w)
			NaClO2 (L/h)	HCl (L/h)
CDKc 150	8～150	20,000	1	1	16～300	1384 x 1080 x 325	55	126
CDKc 400	2～400	20,000	2.67	2.67	40～800	1700 x 1100 x 450	80	177
CDKc 900	45～900	20,000	6	6	90～1800	2000 x 1130 x 510	95	244
CDKc 2000	100～2,000	20,000	13.3	13.3	200～4,000	2000 x 1320 x 550	160	410
CDKc 2800	140～2,800	20,000	18.7	18.7	280～5,600	2000 x 1320 x 550	160	410
CDKc 7300	365～7,300	20,000	48.7	48.7	730～14,600	2300 x 1500 x 560	175	505
CDKc 12000	600～12,000	20,000	80	80	1,200～24,000	2300 x 1500 x 560	180	505

* Reference value when the injection concentration is 0.5 mg / L
The generated 20,000 mg / L chlorine dioxide water is first diluted with bypass water (200 mg / L or less recommended).
Power supply voltage AC100-240V 50 / 60Hz

About chlorine dioxide
