basic design

Recovery rate	40%
Design water temperature	15 degrees
Design salt concentration (raw water)	< 40,000ppm
Desalting rate	97-99%
Minimum supply pressure	0.2 MPa

Material

High pressure piping	SUS904L
Low pressure piping	PVC
flame	PPO
Waterproof standard	IP55

Membrane element housing

style	Spiral type element
Manufacturer	Hydranautics (Nitto Denko)
Membrane type	TFC (polyamide)
Average flux	34.1m3/days
Desalting rate	99.7%
Housing material	FRP
Housing pressure	8.2 MPa (1200psi)

Check filter

Housing material	PVC
Cartridge filter	5 microns (nominal)

Model / Specifications

Model	PMSWRO-10	PMSWRO-15	PMSWRO-20	PMSWRO-25	PMSWRO-30	PMSWRO-40
Permeated water volume	10m3/h	15m3/h	20m3/h	25m3/h	30m3/h	40m3/h
Supply	25m3/h	37.5m3/h	50m3/h	62.5m3/h	75m3/h	100m3/h
Concentrated water amount	15m3/h	22.5m3/h	30m3/h	37.5m3/h	45m3/h	60m3/h
Pump / motor
model	APP10.2	APP17	APP22	APP26	APP30	APP43
maker	Danfoss	Danfoss	Danfoss	Danfoss	Danfoss	Danfoss
Number of units	1	2	1	1	1	1
Electric energy	22kW	37kW	45kW	75kW	90kW	132kW
Energy recovery unit
model	PX-70S	PX-140S	PX-140S	PX-180	PX-220	PX-300
maker	ERI	ERI	ERI	ERI	ERI	ERI
Number of units	1	1	1	1	1	1
Membrane element housing
Number of membranes	20	28	36	48	56	77
Array	4/element	4/element	6/element	6/element	7/element	7/element
	3:2	4:3	6 parallel	8 parallel	8 parallel	11 parallel
Check filter
Check filter	HXP-BF-2	HXP-BF-2	HXP-BF-2	HXP-BF-2	HXP-BF-2	HXP-BF-2
Filter length	40 inch	40 inch	40 inch	40 inch	40 inch	40 inch
Number of filters	1	2	2	3	3	4
Transportation related matters
Container size	20 Feet	40 Feet	40 Feet	40 Feet	40 Feet	40 Feet
Number of containers	1	1	1	1	1	1
Shipping container weight	5t	9t	10t	12t	15t	18t

* Container size
20 feet: L6.0m x W2.4m x H2.4m
40 feet: L12m x W2.4m x H2.4m
